DESCRIPTION of Amiko Mini Combo Extra

FULL HD DIGITAL H.265/HEVC SATELLITE & T2 TERRESTRIAL / CABLE RECEIVER & MEDIA PLAYER

• Conax Embedded Card Reader

• H.265 / HEVC Codec support

• External IR Sensor

• MKV, AVI, MPEG, TS, VOB, MP3, JPEG Playback

• Full HD 1080p Output

• YouTube Videos

• Ethernet Connection

• USB WiFi Support (Ralink RT5370 chip only)

• Two High Speed USB2.0 Slots

• DVB-S2 Satellite & DVB-T2/C Terrestrial / Combo Receiver

• One Conax Embedded card reader

• H.265 / HEVC Codec support

• 5000 channels (TV and Radio) programmable

• External IR Sensor (Included in the package)

• Two High Speed USB 2.0 Connection

• Ethernet Connection & USB WiFi Support (Ralink RT5370 chip only)

• YouTube videos

• RSS Reader & Weather Forecast Functions (Ethernet or WiFi connection required)

• DiSEqC 1.0, 1.1, 1.2 and USALS Compatible

• Full HD (1080p) Output via HDMI

• Channel Recording to External Storage Devices (from one frequency only)

• Timeshift support

• Channel Recording & Timeshifting Simulteniously (optional, only from same frequency)

• Channel switching time less than 1 second

• True-color, User Friendly On-Screen Display (OSD)

• Full Picture In Graphic (PIG) function

• Electronic Program Guide (EPG) for on screen channel information

• Subtitle supported

• Teletext supported by VBI insertion and software emulation

• Parental lock facility by channel and program event

• Program and Channel information transfer from receiver to receiver

• Multi-Language support

• RTC (Real-Time-Clock)

• Power Consumption in Stand-By: <0.5W

Tuner & Demodulation

• Tuner Type: DVB-S / DVB-S2

• Input Connector: F-type, Connector, Female

• Loop Through: F-type, Connector, Female

• Signal Level: -65 to -25 dBm

• LNB Power & Polarization: Vertical: +13V/+14V,

• Horizontal: +18V/+19V

• Current: Max. 300mA

• Overload Protection

• 22KHz Tone Frequency: 22±1KHz

• DiSEqC Control: Version 1.0, 1.1, 1.2, USALS

• Demodulation: QPSK, 8PSK

• Input Symbol Rate: 2-45 Mbps,

• FEC: 1/2, 2/3, 3/4, 5/6, 7/8 and Auto

• Tuner Type: DVB-T2 / DVB-C

• Frequency Range: 48~862MHz

• RF Input Level: -80dBm to -20dBm

• Antenna power output: DC 5V at max 75mA, Overload protection

• Demodulation: COFDM 1K, 2K, 4K, 8K normal and extended, 16K normal and extended, 32K normal and extended

• Input Symbol Rate: 1.0 ~ 7.0Ms/s

• Constellations: QPSK, 16QAM, 64QAM, 256QAM / Both rotated and non-rotated

• Guard Intervals: 1/4, 19/256, 1/8, 19/128, 1/16, 1/32, 1/128

• Code Rate: 1/2, 3/5, 2/3, 3/4, 5/6

• System Resources

• Main Processor: up to 2000DMIPS CPU

• Flash Memory: 8 MiB

• DDR RAM: 256 MiB (DDR3 1866MHz) MPEG TS A/V Decoding

• Transport Stream: MPEG-2, MPEG-4 (H.264)

• Input Rate: Max.120Mbit/s

• Aspect Radio: 4:3, 16:9, Letter Box

• Video Decoding: HEVC MP@L4.1, MPEG2 MP@HL, MPEG-4 part 10/H.264

• Video Resolution: 720*480p/i, 720*576p/i, 1280*720p, 1920*1080p/i

• Audio Decoding: MPEG-1 layer I/II, MPEG-2 layer II, Dolby Digital, AAC

• Audio Mode: Left / Right / Stereo/ Mono

• Sampling Rate: 32, 44.1 and 48KHz

• A/V & Data Input/Output

• AV OUT: Video RGB&CVBS output, Audio L/R output (SCART)

• LAN: 10/100M RJ-45 Ethernet Connection

• USB: Two USB 2.0 slots

• HDMI: VER1.3, Type A, Dolby Digital Bit-Stream Output

• S/PDIF: Coaxial

• IR: External IR input (jack type)

• Physical Specifications

• Size[W*H*D]: 144mm x 40mm x 110mm

• Net Weight: 0.50 Kg

• Operation Temperature: 0°C~+45°C

• Storage Temperature: -10°C~+70°C

• Storage Humidity: 5%~95% RH (Non-Condensing)
